SiT9201是业界首个带有嵌入式MEMS谐振器的一个输出时钟发生器。该器件具有最宽的频率范围,最低的功耗,最佳的稳定性和最短的交货时间在消费,网络,工业和其他应用程序等行业。它配备了5-pin,小的SOT23封装,提供了最好的板级焊点的可靠性,能够使成本低,optical-ONLY板级检查。

功能特性 技术参数 封装包装 产品应用
  • Any frequency between 1 MHz and 110 MHz accurate to 6 decimal places
  • Operating temperature from -40°C to 85°C. Refer to SiT2018 for -40°C to 85°C option and SiT2020 for -55°C to 125°C option
  • Excellent total frequency stability as low as ±20 ppm
  • Low power consumption of 3.6 mA typical
  • Fast startup time of 5 ms
  • LVCMOS/HCMOS compatible output
  • 5-pin SOT23-5: 2.9mm x 2.8mm
  • Pb-free, RoHS and REACH compliant
  • For AEC-Q100 one- output clock generators, refer to SiT2024 and SiT2025
