SiT3808

首页 > 产品中心 > SITIME > 压控振荡器VCXO >

频率范围（MHz）：1-80MHZ

牵引范围：±25, ±50, ±100, ±150, ±200, ±400, ±800, ±1600 PPM

工作电压（V）：1.8、2.5V、3.3V

10倍于石英的牵引斜率：<=1%;

兼容LVCMOS/LVTTL 电平输出

工作温度（℃）： -20 to +70、-40 to +85

控制电压：0-Vdd

封装（mm）：3.2×2.5（4pin），5.0×3.2（6pin），7.0×5.0（6pin）mm

Any frequency between 1 MHz and 80 MHz with 6 decimal places of accuracy

100% pin-to-pin drop-in replacement to quartz based VCXO

Frequency stability as low as ±10 PPM

Widest pull range options from ±25 PPM to ±1600 PPM

Superior pull range linearity of <= 1%, 10 times better than quartz

LVCMOS/LVTTL compatible output

Three industry-standard packages: 3.2 mm x2.5 mm (4-pin), 5.0 mm x 3.2 mm (6-pin),7.0 mm x 5.0 mm (6-pin)

Outstanding siicon reliability of 2 FIT (10x improvement over quartz-based devices)

Ideal for telecom clock synchronization, instrumentation, low bandwidth analog PLL,jitter cleaner, clock recovery, audio, video, FPGA, broadband and networking

电信设备
无线基站
网络和通信电子
网络视频系统和数字化仪
机顶盒（STB）
抖动清洁剂
网络音频系统
低带宽模拟锁相环（PLL）
FGPA数据恢复
